No. 1 30 × 80 mm Glass Balustrade Base Shoe
No. 1 glass balustrade base shoe with a 30 × 80 mm section, 3.5 m length and 8 mm wall thickness. Catalog lists compatibility with 12 mm glass. Confirm glass build-up, gasket set, fixing method and finish before ordering.
No. 1 30 × 80 mm Glass Balustrade Base Shoe
No. 1 glass balustrade base-shoe profile for securing the lower edge of glass panels in staircase and railing systems. Catalog specifications: 30 × 80 mm section, 3.5 m length, 8 mm wall thickness and 12 mm listed glass compatibility. Final glass build-up, gasket set, mounting arrangement, fixing parts and finish must be confirmed before ordering. Contact THETOP with project drawings, glass specification, required length and quantity for quotation.
Product and Selection Information
| Profile | No. 1 |
|---|---|
| Catalog specifications | 30 × 80 mm section, 3.5 m length, 8 mm wall thickness and 12 mm listed glass compatibility |
| Glass and gasket configuration | Confirm the actual glass build-up and matching gasket set for the selected version. |
| Mounting and fixing | Confirm mounting orientation, substrate, fixing positions and compatible anchor arrangement. |
| Finish and supplied parts | Confirm material details, finish availability and the included component list in the quotation. |
Before Ordering
Provide the panel layout and glass specification, installation drawing, profile lengths and quantity, substrate, required finish and project location. Confirm the exact section and mounting configuration before fabrication. For replacements, send photos and measurements of the existing profile, glass seat, gaskets and fixing arrangement.
No. 1 Buyer FAQs
How do I identify the correct profile?
Select No. 1 by its complete product drawing and catalog dimensions. Compare the section, glass seating arrangement, mounting positions and mating parts with your project layout; dimensions alone do not establish interchangeability.
What glass specification should I provide?
The catalog lists 12 mm glass compatibility. Provide the actual glass build-up, panel dimensions and required gasket set, then confirm the selected profile and configuration before ordering.
Which mounting and fixing details need confirmation?
Send the mounting orientation, substrate and installation drawing. Request the fixing positions, compatible anchor details, profile joint arrangement and installation instructions for the exact supplied configuration.
Can the catalog dimensions establish a railing load rating?
No. Confirm suitability within the complete railing design, including glass specification, mounting substrate and fixings. Request the relevant system information for your intended installation.
What information is needed for a quotation?
Send No. 1, required lengths and quantity, panel layout, glass specification, substrate, mounting drawing, finish, delivery address and postcode. Confirm included gaskets, fixing parts, end components and any separately ordered items.
